On the 5-cylinder 2.5 TDI Volkswagen Crafter (89 bhp BJJ, 109 bhp BJK, 136 bhp BJL, and 163 bhp BJM), drivers often report two alarming symptoms: the brake pedal suddenly goes rock-hard on the second press when reversing into a loading bay, or dark engine oil drips steadily from the mechanical pump bolted to the cylinder head. Both faults trace directly to a worn cam-driven Brake Vacuum Pump (OEM 076145100 / A076145100).
1. How the Cam-Driven Vacuum Pump (076145100) Fails on the 2.5 TDI 5-Cylinder
Diesel engines do not generate manifold vacuum like petrol engines; instead, the brake servo booster relies entirely on mechanical rotary-vane vacuum pump 076145100 driven off the camshaft slot. Over high commercial mileage, the internal rotary vane wears the alloy pump housing, dropping vacuum below the -0.75 bar required by the brake booster—while the outer viton/metal mating gasket weeps engine oil.
2. UK Workshop Diagnostic Fault Codes, Symptoms & Root Causes
| Fault Code / Defect | On-Road / MOT Symptom | Root Cause & Permanent Workshop Fix |
|---|---|---|
| DVSA MOT Section 1.1.10 (Dangerous/Major) | Brake Servo Assistance Defective / Pedal Hard Under Repeated Application | Worn rotary vane or leaking non-return spigot on vacuum pump 076145100. |
| DVSA MOT Section 8.4.1 (Major Defect) | Engine Oil Leaking Excessively from Cylinder Head Drive Flange | Failed perimeter gasket on vacuum pump 076145100. |
3. Verified OEM Part Number Cross-Reference & UK Fitment Guide
| OEM Reference | UK Vehicle Application | Component & Workshop Spec |
|---|---|---|
| BD1114 — 076145100 / 076 145 100 | VW Crafter 30-35 & 30-50 2.5 TDI (BJJ, BJK, BJL, BJM — 2006–2013) | Complete Mechanical Brake Vacuum Pump with Cylinder Head Gasket |
| BD1074 — Sprinter W906 / Crafter Arch Kit | VW Crafter 1st Gen (2006–2017) & Mercedes Sprinter W906 | 4-Piece ABS Wheel Arch Wing Flare Protector Set |
| BD1103 — Sprinter / Crafter Sill Guards | VW Crafter & Mercedes Sprinter (2006–2017) | 2-Piece Front Door Step Entry Kick Plate Scuff Protectors |
🔩 Direct-Fit OEM-Spec Parts In Stock (Birmingham UK Warehouse)
✓ Same-Day Dispatch Before 6:00 PM UK
4. Step-by-Step UK Workshop Fitting Procedure & Torque Specs
- Disconnect the Vacuum Servo Hose Carefully: Twist and pull the vacuum booster hose off the pump outlet—never lever against the plastic check-valve barb.
- Unbolt the Old 076145100 Pump & Note Camshaft Drive Slot Orientation: Remove the mounting bolts, withdraw the old pump, and note the exact angle of the female camshaft drive slot.
- Align the New BuyDay BD1114 Drive Dog & Torque to 20 Nm: Pre-lubricate the drive coupling lug with clean 5W-30 engine oil, align the lug with the camshaft slot so the pump flange sits dead flush against the head by hand (never pull it home with the bolts!), and tighten to 20 Nm.
5. Master Mechanic Q&A: UK Workshop & MOT Questions Answered
Q: Does BuyDay part BD1114 (076145100) come with the new cylinder head gasket?
Dave Mercer (Master Tech): Yes, BD1114 is supplied complete with the precision mating gasket ready for direct bolt-on installation.
Q: Why did my new vacuum pump crack the flange when tightening the bolts?
Dave Mercer (Master Tech): If the pump's drive dog is not aligned with the camshaft slot before tightening the mounting bolts, tightening the bolts forces the dog against the cam face and snaps the alloy ear—always seat the pump flush by hand first!
